Communication: 1×CAN
Protocol: User-defined
Resource: 8 keys 1×DOH
| Size | 111.1×68.1×39.1 mm |
| Material | Plastic housing + Silicone panel (hemlines for lower surface mounting) |
| Working Voltage | 8～32V |
| Working temperature | -40～+85℃ |
Communication: 1×CAN
Protocol: User-defined
Resource: 8 keys 1×DOH
Status Indicator: RGB Monocolor LED
Backlight: White Adjustable Brightness
Customized Key Pattern on Demand
With hemlines
32-bit high performance MCU
1 channel CAN, support customization
1 high side output, can drive load directly
Key life up to 500,000 times
High brightness white backlight
All input ports support misconnection of power and ground
All output ports with short-circuit and over-temperature protection
Protection rating: IP65/IP67 (with cable)
Hemlines design to reduce embedded installation height
Crawler crane control system
Loader control system
Fire truck control system
Rotary drilling rig control system
